12.11.3 SVC Control (EFC 5610 ONLY)
SVC control loop configuration
Code Name Setting range Default Min. Attri.
C3.00 Speed loop proportional gain 0.00...655.35 DOM 0.01 Run
C3.01 Speed loop integral time 0.01...655.35 ms DOM 0.01 Run
C3.05 Current loop proportional gain 0.1...1,000.0 DOM 0.1 Run
C3.06 Current loop integral time 0.01...655.35 ms DOM 0.01 Run
C3.20 Low speed torque limitation 1…200 % 100 1 Stop
Speed control mode
The frequency converter is by default running in speed control mode. In this
mode, the frequency converter follows the frequency reference change, and the
output torque changes with the load.
Code Name Setting range Default Min. Attri.
C3.44 Torque positive limit 0.0…200.0 % 150.0 0.1 Run
C3.45 Torque negative limit 0.0…200.0 % 150.0 0.1 Run
C3.44 'Torque positive limit' and C3.45 'Torque negative limit' are used to limit
the output torque in speed control mode. The former parameter is used when
the frequency converter is running on electric drive mode, while the latter pa-
rameter is used when the frequency converter is running on regeneration mode.
EFC x610 Series
Bosch Rexroth AG
Functions and Parameters
DOK-RCON03-EFC-X610***-IT05-EN-P
225/389
