12.13 ASF Function
12.13.1 Function Description
EFC x610 supply the function of ASF (Application Specific Firmware), the fre-
quency converter can load different ASF (such as "Water supply", "Tension con-
trol" , etc.) based on different applications. This can realize flexible and fast re-
quirement from user.
This chapter introduce the relavant information of ASF. For detailed information
about ASF function and operation, please refer to each ASF Instruction Manual.
12.13.2 ASF Parameter
The table below lists the ASF parameters loaded by frequency converter.
Code Name Setting range Default* Min. Attri.
F0.01 ASF version – 0.00 – Read
F0.02 ASF identifier 0x0000 … 0x0FFF 0x0000 – Read
F0.03
ASF API required ver-
sion
– 0.00 – Read
F0.06 ASF trial time left 0…65,535 0 – Read
F0.07 ASF API version – ** – Read
F0.10 ASF status 0x0000H…0xFFFFH 0x0000 1 Read
F0.20 ASF command 1 – 0 – Read
F0.21 ASF command 2 – 0 – Read
F0.22 ASF command 3 – 0 – Read
F0.23 ASF command 4 – 0 – Read
● *: The default value depends on the specific ASF function.
● **: The value depends on firmware version of the frequency con-
verter.
Each bit of F0.10 defines the status information of current ASF.
Bit
Definition
15..14 Reserved
13 Error-Stack overflow
12 Error-Runtime timeout
11 Reserved
10 Error-API incompatible
9 Error-Invalid
8 Error-Trial time expired
EFC x610 Series Bosch Rexroth AG
Functions and Parameters
DOK-RCON03-EFC-X610***-IT05-EN-P
235/389
