Bit Definition
7...3 Reserved
2 ASF authenticated
1 API compatible
0 ASF activated
Tab. 12-21: ASF status bit definition
When the frequency converter loaded an effective and certified ASF, the value of
F0.10 is 0x0007.
F0.20...F0.23 are the parameters used by ASF platform and extension card inter-
face. For detailed information about the definition and operation, please refer to
the Instruction Manual for extension card and specific ASF.
The range of ASF parameter is F1.00...F5.99, each parameter and its group num-
bers are defined by ASF instance.
Bosch Rexroth AG
Functions and Parameters
EFC x610 Series
236/389
DOK-RCON03-EFC-X610***-IT05-EN-P
