C1: Motor and system parameters
Code Name Setting range Default Min. Attri.
C1.00 Motor type
0: Asynchronous motor
1: Synchronous motor (only
for EFC 5610)
0 – Stop
C1.01 Motor parameter tuning
0: Inactive
1: Static auto-tuning
2: Rotational auto-tuning
①
0 – Stop
C1.05 Motor rated power 0.1...1,000.0 kW DOM 0.1 Stop
C1.06 Motor rated voltage 0...480 V DOM 1 Stop
C1.07 Motor rated current 0.01...655.00 A DOM 0.01 Stop
C1.08 Motor rated frequency 5.00...400.00 Hz 50.00 0.01 Stop
C1.09 Motor rated speed 1...30,000 rpm DOM 1 Stop
C1.10 Motor rated power factor
0.00...0.99
②
0.00 0.01 Stop
C1.11
Motor poles
①
2...128 DOM 1 Stop
C1.12 Motor rated slip frequency 0.00...20.00 Hz DOM 0.01 Run
C1.13
Motor inertia mantissa
①
1...5,000 DOM 1 Stop
C1.14
Motor inertia exponent
①
0...7 DOM 1 Stop
C1.15 Torque constant 0.01…200 DOM 0.01 Run
C1.20 Motor no-load current 0.00...[C1.07] A DOM 0.01 Stop
C1.21 Stator resistance 0.00...50.00 Ω DOM 0.01 Stop
C1.22 Rotor resistance 0.00...50.00 Ω DOM 0.01 Stop
C1.23 Leakage inductance 0.00...200.00 mH DOM 0.01 Stop
C1.24 Mutual inductance 0.0...3,000.0 mH DOM 0.1 Stop
C1.69
Motor thermal model protection
setting
0: Inactive
1: Active
1 – Stop
C1.70 Motor overload pre-warning level 100.0...250.0 % 100.0 0.1 Run
C1.71 Motor overload pre-warning delay 0.0...20.0 s 2.0 0.1 Run
C1.72 Motor thermal sensor type
0: PTC, KTY84/130
2: PT100; 3: PT1000
0 – Stop
C1.73
Motor thermal sensor protection
level
0.0...10.0 V 2.0 0.1 Stop
C1.74
Motor thermal model protection
time constant
0.0...400.0 min DOM 0.1 Stop
C1.75 Low speed derating frequency 0.10...300.00 Hz 25.00 0.01 Run
C1.76 Zero speed load 25.0...100.0 % 25.0 0.1 Run
EFC x610 Series Bosch Rexroth AG
Appendix
DOK-RCON03-EFC-X610***-IT05-EN-P
335/389
