REXROTH EFC 3610 Series User Manual

E8: Standard communication parameters
Code Name Setting range Default Min. Attri.
E8.00 Communication protocol
0: Modbus
1: Extension card
0 – Stop
E8.01
Communication error
detection time
0.0...60.0 s
(0.0: Inactive)
0.0 0.1 Stop
E8.02
Communication error
protection mode
0: Freewheeling stop
1: Keep running
1 – Stop
E8.03
Communication process
data loss behavior
0: Decelerating stop
1: Freewheeling stop
2: Keep running
0 – Stop
E8.10 Modbus baud rate
0: 1,200 bps; 1: 2,400 bps
2: 4,800 bps; 3: 9,600 bps
4: 19,200 bps; 5: 38,400 bps
3 – Stop
E8.11 Modbus data format 0...3 0 – Stop
E8.12 Modbus local address 1...247 1 1 Stop
E8.13
Modbus level / edge sen-
sitivity selection
0: Level sensitive
1: Edge sensitive
1 – Stop
Setting range of E8.11:
0: N, 8, 1 (1 start bit, 8 data bits, 1 stop bit, no parity)
1: E, 8, 1 (1 start bit, 8 data bits, 1 stop bit, even parity)
2: O, 8, 1 (1 start bit, 8 data bits, 1 stop bit, odd parity)
3: N, 8, 2 (1 start bit, 8 data bits, 2 stop bits, no parity)
EFC x610 Series
Bosch Rexroth AG
Appendix
DOK-RCON03-EFC-X610***-IT05-EN-P
353/389
