10.6 Fast Access to Parameters with Button Combinations
EFC x610 provides fast access to parameters within a parameter group with
'<Func> + <▲>' or '<Func> + <▼>' combinations. This function is only valid for the
tens digit of the function code index '□□.x□'.
● Pressing '<Func> + <▲>' once: '□□.x□' is changed to '□□.x+1□'
● Pressing '<Func> + <▼>' once: '□□.x□' is changed to '□□.x-1□'
Example: The frequency converter is now displaying 'E0.07' after setting with
<Func>, <Set>, <▲> and <▼> buttons.
If 'E0.17' needs to be displayed based on 'E0.07', <▲> button has to be pressed
for 10 times in the traditional way as described in the above figure. However,
with button combination function, it is only necessary to press '<Func> + <▲>'
buttons once.
● The parameter fast access function is only available when [b0.00]
= 0, 1, or 2, unavailable with parameters in groups '-PF-' or '-EP-'
● Press <Func> button and do not release it until <▲> or <▼> button
has been pressed.
● Press <▲> or <▼> button within 2 s if <Func> button is pressed.
● If the index of parameters is not continuous in a specific parame-
ter group, the adjacent parameter will be accessed. For example,
the display of 'E0.01' should be changed to 'E0.11' with '<Func> +
<▲>' button function. However, parameter E0.11 is unavailable in
group E. While the adjacent parameter is E0.15. In this case,
'E0.15' is accessed and displayed.
EFC x610 Series Bosch Rexroth AG
Operating Panel and Dust Cover
DOK-RCON03-EFC-X610***-IT05-EN-P
91/389
