REXROTH EFC 3610 Series User Manual

H8: I/O card parameters
Code Name Setting range Default Min. Attri.
H8.00 EX1 input
0...46
0 – Stop
H8.01 EX2 input 0 – Stop
H8.02 EX3 input 0 – Stop
H8.03 EX4 input 0 – Stop
H8.05 EAI input mode
0: 0...20 mA
1: 4...20 mA
2: 0…10 V
3: 0…5 V
4: 2...10 V
5: -10...10 V
0 – Stop
H8.06 EAI input polarity setting 0...2 1 – Stop
H8.08 EAI curve selection
0: Curve 0
1: Curve 1
2: Curve 2
1 – Stop
H8.09 EAI filter time 0.000...2.000 0.100 0.001 Run
H8.10 EAI gain 0.00...10.00 1.00 0.01 Run
H8.15 Input curve 0 minimum -120.0 %...[H8.17] 0.0 0.1 Run
H8.16 Input curve 0 minimum frequency -[E0.09]...[E0.09] Hz 0.00 0.01 Run
H8.17 Input curve 0 maximum [H8.15]...120.0 % 100.0 0.1 Run
H8.18 Input curve 0 maximum frequency -[E0.09]...[E0.09] Hz 50.00 0.01 Run
H8.20 EDO output setting
0...20
1 – Stop
H8.21 Extended relay output selection 1 – Stop
H8.25 EAO output mode
0: 0…10 V
1: 0...20 mA
0 – Run
H8.26 EAO output selection
0: Running frequency
1: Set frequency
2: Output current
4: Output voltage
5: Output power
6: AI1 analog input
7: AI2 analog input
8: EAI analog input
11: Motor temperature sen-
sor power
0 – Run
EFC x610 Series Bosch Rexroth AG
Appendix
DOK-RCON03-EFC-X610***-IT05-EN-P
359/389
