REXROTH EFC 3610 Series User Manual

Code Name Setting range Default Min. Attri.
H8.27 EAO gain 0.00...10.00 1.00 0.01 Run
H8.87 I/O card output channel diagnosis
0: Inactive
1: EAO diagnosis
2: EDO diagnosis
3: ERO diagnosis
4: All output diagnosis
1 – Stop
Setting range of H8.00...H8.03:
0: No function assigned
1: Multi-speed control input 1
2: Multi-speed control input 2
3: Multi-speed control input 3
4: Multi-speed control input 4
10: Acceleration/deceleration time 1 activation
11: Acceleration/deceleration time 2 activation
12: Acceleration/deceleration time 3 activation
15: Freewheeling stop activation
16: Stop DC-braking activation
20: Frequency Up command
21: Frequency Down command
22: Up/Down command reset
23: Torque/Speed control switch
25: 3-wire control
26: Simple PLC stop
27: Simple PLC pause
30: Second frequency setting source activation
31: Second run command source activation
32: Error signal N.O. contact input
33: Error signal N.C. contact input
34: Error reset
35: Forward running (FWD)
36: Reverse running (REV)
37: Forward jog
38: Reverse jog
39: Counter input
40: Counter reset
Bosch Rexroth AG
Appendix
EFC x610 Series
360/389
DOK-RCON03-EFC-X610***-IT05-EN-P
