E2: Output terminal parameters
Code Name Setting range Default Min. Attri.
E2.01 DO1 output setting 0...99 1 – Stop
E2.02 DO1 pulse output setting
0: Converter output frequency
1: Converter output voltage
2: Converter output current
99: Inactive
0 – Stop
E2.03
Pulse output maximum
frequency
0.1...32.0 kHz 32.0 0.1 Run
E2.15 Relay 1 output selection 0...99 1 – Stop
E2.25 AO1 output mode
0: 0...10 V
1: 0...20 mA
0 – Run
E2.26 AO1 output setting
0: Output frequency
1: Setting frequency
2: Output current
4: Output voltage
5: Output power
6: AI1 analog input
7: AI2 analog input
8: EAI analog input
11: Motor temperature sensor
power supply
99: Inactive
0 – Run
E2.27 AO1 gain 0.00...10.00 1.00 0.01 Run
E2.40 Rated voltage
1P 200...240 VAC 220
1 Stop
3P 380...480 VAC 380
E2.50 Output curve 1 minimum 0.0 %...[E2.52] 0.0 0.1 Run
E2.51 Output curve 1 minimum value 0.00...100.00 % 0.00 0.01 Run
E2.52 Output curve 1 maximum [E2.50]...100.0 % 100.0 0.1 Run
E2.53 Output curve 1 maximum value 0.00...100.00 % 100.00 0.01 Run
E2.70 Frequency detection width 0.00...400.00 Hz 2.50 0.01 Run
E2.71 Frequency detection level FDT1 0.01...400.00 Hz 50.00 0.01 Run
E2.72
Frequency detection level
FDT1 width
0.01...[E2.71] Hz 1.00 0.01 Run
E2.73 Frequency detection level FDT2 0.01...400.00 Hz 25.00 0.01 Run
EFC x610 Series Bosch Rexroth AG
Appendix
DOK-RCON03-EFC-X610***-IT05-EN-P
345/389
