13.5.2 Automatic Error Reset
Automatic error reset function is used to ensure continuous running without hu-
man intervention in the case of occasional errors, such as overcurrent or over-
voltage at start or in the run mode. This function can be activated by setting
[E9.00] ≠0.
When an error occurs, the frequency converter stops the output and the related
error code is displayed at the same time. The system remains in idle mode for
delay time [E9.01]. Then the error will automatically be reset and a run com-
mand will be generated to restart the frequency converter. This sequence will be
performed [E9.00] times. If the error still exists, the frequency converter re-
mains in idle mode and no longer performs automatic restart attempts. In this
case, a manual error reset is required to resume the operation.
Automatic error reset is valid for the following errors: OC-1, OC-2, OC-3, OE-1,
OE-2, OE-3, OE-4, OL-1, OL-2, UE-1, E-St, OH and UH.
Code Name Setting range Default Min. Attri.
E9.00 Automatic error reset attempts 0...3 (0: Inactive) 0 – Stop
E9.01 Automatic error reset interval 0.1...60.0 s 10.0 0.1 Stop
*:
1. If [E9.00] ≠0 and [E0.45] = 0, then error "UE-1" reset once ev-
ery time, the remaining error reset time decrease once.
2. If [E9.00] ≠0 and [E0.45] ≠0, then reset time of error "UE-1" is
without limitation.
3. If [E9.00] = 0 and [E0.45] ≠0, then reset time of error "UE-1" is
without limitation.
Bosch Rexroth AG
Diagnosis
EFC x610 Series
252/389
DOK-RCON03-EFC-X610***-IT05-EN-P
