REXROTH EFC 3610 Series User Manual

7.4.2 Dimensions
Frame
Model
①
Dimensions [mm]
Screw
size
②
Net
weight
[kg]
W H D w h d Ø
B 0K40 95 166 167 66 156 159 4.5 M4 1.5
B 0K75 95 166 167 66 156 159 4.5 M4 1.5
C 1K50 95 206 170 66 196 162 4.5 M4 1.9
D 2K20 120 231 175 80 221 167 4.5 M4 2.6
Tab. 7-5: EFC x610 1P 200 VAC dimensions
Frame
model
①
Dimensions [mm]
Screw
size
②
Net
weight
[kg]
W H D w h d Ø
B 0K40 95 166 167 66 156 159 4.5 M4 1.5
B 0K75 95 166 167 66 156 159 4.5 M4 1.5
C 1K50 95 206 170 66 196 162 4.5 M4 1.9
C 2K20 95 206 170 66 196 162 4.5 M4 1.9
D 3K00 120 231 175 80 221 167 4.5 M4 2.6
D 4K00 120 231 175 80 221 167 4.5 M4 2.6
E 5K50 130 243 233 106 228 225 6.5 M6 3.9
E 7K50 130 243 233 106 228 225 6.5 M6 4.3
F 11K0 150 283 233 125 265 225 6.5 M6 5.7
F 15K0 150 283 233 125 265 225 6.5 M6 6.4
G 18K5 165 315 241 140 300 233 6.5 M6 8.0
G 22K0 165 315 241 140 300 233 6.5 M6 8.5
H
③
30K0 250 510 272 200 492 264 7.0 M6 27.5
H
③
37K0 250 510 272 200 492 264 7.0 M6 29.5
I
③
45K0 265 585 325 200 555 317 11.0 M10 39.0
I
③
55K0 265 585 325 200 555 317 11.0 M10 42.0
J
③
75K0 325 760 342 200 727 334 11.0 M10 54.0
J
③
90K0 325 760 342 200 727 334 11.0 M10 61.0
Tab. 7-6: EFC x610 3P 400 VAC dimensions
Bosch Rexroth AG
Frequency Converter Mounting
EFC x610 Series
38/389
DOK-RCON03-EFC-X610***-IT05-EN-P
