30K0...90K0: available with ONLY EFC 5610.
Please select the power rating of the frequency converter according
to the motor rated power on the nameplate.
Model
Motor power
ND [kW]
380 V / 480 V
Input current [A]
380 V / 480 V
Output current [A]
Output capacity
[kVA]
5K50 7.5 21.0 / 16.7 16.8 / 13.3 11.1
7K50 11.0 28.0 / 22.2 24.3 / 19.2 16.0
11K0 15.0 37.8 / 29.9 32.4 / 25.6 21.3
15K0 18.5 45.8 / 36.3 39.2 / 31.0 25.8
18K5 22.0 52.7 / 41.7 45.0 / 36.0 29.7
22K0 30.0 71.2 / 56.3 60.8 / 48.0 40.0
30K0 37.0 69.6 / 55.1 73.7 / 58.3 48.5
37K0 45.0 84.2 / 66.6 89.1 / 70.5 58.7
45K0 55.0 105.0 / 83.0 108.0 / 86.0 71.3
55K0 75.0 140.0 / 111.0 147.0 / 116.0 96.6
75K0 90.0 167.0 / 133.0 176.0 / 139.0 115.7
90K0 110.0 205.0 / 162.0 212.0 / 168.0 139.6
Tab. 6-4: 3P 400 VAC 5K50...90K0, electric data, ND (normal duty)
30K0...90K0: available with ONLY EFC 5610.
Please select the power rating of the frequency converter according
to the motor rated power on the nameplate.
Bosch Rexroth AG
Frequency Converter Overview
EFC x610 Series
24/389
DOK-RCON03-EFC-X610***-IT05-EN-P
