REXROTH EFC 3610 Series User Manual

Code Name Setting range Default Min. Attri.
E0.36 Start frequency 0.00...50.00 Hz 0.05 0.01 Stop
E0.37 Start frequency holding time 0.0...20.0 s 0.1 0.1 Stop
E0.38 Start DC-braking time 0.0...20.0 s (0.0: Inactive) 0.0 0.1 Stop
E0.39
Start DC-braking current
①
0.0...150.0 % 0.0 0.1 Stop
E0.41
Automatic start / stop frequency
threshold
0.01…[E0.09] Hz 16.00 0.01 Stop
E0.45 Power loss restart mode
0: Inactive
1: Active for panel control
2: Active only for 2-wire con-
trol
0 – Stop
E0.46 Power loss restart delay 0.0...10.0 s 1.0 0.1 Stop
E0.50 Stop mode
0: Decelerating stop
1: Freewheeling stop
2: Freewheeling with stop
command, decelerating with
direction change
0 – Stop
E0.52
Stop DC-braking initial
frequency
0.00...50.00 Hz 0.00 0.01 Stop
E0.53 Stop DC-braking time 0.0...20.0 s (0.0: Inactive) 0.0 0.1 Stop
E0.54
Stop DC-braking current
①
0.0...150.0 % 0.0 0.1 Stop
E0.55 Overexcitation braking factor 1.00...1.40 1.10 0.01 Run
E0.60 Jog frequency 0.00...[E0.08] Hz 5.00 0.01 Run
E0.61 Jog acceleration time 0.1...6,000.0 s 5.0 0.1 Run
E0.62 Jog deceleration time 0.1...6,000.0 s 5.0 0.1 Run
E0.70 Skip frequency 1 0.00...[E0.09] Hz 0.00 0.01 Stop
E0.71 Skip frequency 2 0.00...[E0.09] Hz 0.00 0.01 Stop
E0.72 Skip frequency 3 0.00...[E0.09] Hz 0.00 0.01 Stop
E0.73 Skip frequency range 0.00...30.00 Hz 0.00 0.01 Stop
E0.74
Skip window acceleration
factor
1...100 1 1 Stop
①
: percentage of frequency converter rated current.
Setting range of E0.00, E0.02:
0: Panel potentiometer
1: Panel button setting
2: AI1 analog input
3: AI2 analog input
Bosch Rexroth AG
Appendix
EFC x610 Series
340/389
DOK-RCON03-EFC-X610***-IT05-EN-P
