Ricoh M0A0 - Page 54

2.Installation
42
5. Remove the right cover [A].
6. Cut off the USB port cover [A] with nippers or other such tool.
7. Reattach the right cover.
8. Loosen the two screws and remove the I/F slot cover.
The removed cover will not be reused.
