Ricoh M0A0 - Page 576

2.Mechanism
18
Basic Specifications
Category
Specification
LCD panel
 Size
10.1 inch panel
 Resolution
WSVGA (1024x600)
 Bit width
RGB666 (18 bit color)
 Brightness
200cd/m
2
(typ.)
 Backlight
LED Backlight (life: 15,000 hours)
CPU
ARM Cortex-A9 Dual Core 1GHz (SoC: MCIMX6D5EYM10AC)
Touch panel
Low load touch panel (recognizes touches to two points)
Memory
 Volatile Memory
RAM (DDR3-1066), 2G
 Non-Volatile Memory
eMMC NAND, 8GB
 Uses a 16GB product in SLC Mode.
 Program area and data area for the operating system and applications.
External interfaces
 USB Memory
USB2.0 Host Type-A
 SD Card
SD card slot 1ch (SD*
1
/SDHC*
2
)
*1 Up to 2GB
*2 Up to 32GB
 USB expansion
USB2.0 Host Type-A
(for camera, USB keyboard, USB card reader)
 USB expansion
USB2.0 Host Type-miniB
(for NFC expansion)
 HDMI
HDMI 1.4
(for large screens available as custom order)
Internal interfaces
 Extended Features
microSD card slot
