Ricoh M0A0 - Page 577

2.Mechanism
19
Category
Specification
 When a media is inserted in the microSD card slot, its capacity is shown in the
control panel service mode (Screen Features > Device > microSD card) and
the SMC (in the report for the Smart Operation Panel).
Network
 Wireless LAN
802.11b/g/n
 Bluetooth
Bluetooth4.0
Audio input/output
Monaural speaker 1ch (output: 1 to 2 W), Microphone
RTC accuracy
±52.56 seconds per month (using external crystal oscillator, 20 ppm)
Hard keys
 Extended Feature keys (EX1, EX2, and EX3)
Use for startup in extended mode etc.
 Control panel reboot key
Use to reboot the control panel when it freezes.
LED types
 Main power indicator (blue)
Lights when the power is on. Flashes slowly in Sleep mode.
 [Check Status] indicator lamp (red/blue)
Lights when an error occurs.
 Data In indicator (blue)
Flashes when the machine receives data from a printer driver or LAN-Fax driver.
 Fax indicator (blue)
Flashes while sending or receiving a fax. Lights when there is a received fax document in
the fax memory.
 Media access lamp (blue)
Lights when there is an SD card inserted in the SD card slot.
Maximum power
consumption
4 W or less
(excluding external interfaces and internal feature expansions)
Power consumption
in Sleep mode
0.35 W or less
(When in Sleep mode, power is not supplied to USB devices connected to the USB slots.)
Specification comparison with the previous model
Item
This model
Previous model
Appearance
Control panel size
(Width × Height)
267 × 160 mm
345 × 161 mm
