2.Installation
46
2. Ping "RX" + "MAC address" from the command prompt on a windows PC which is on the same network as the
mainframe.
ï‚· When installing the USB Device Server Option Type M19, the installation status is not shown on the
Configuration Page.
ï‚· The customer should keep the slot covers which were removed.
What Do the LED Indicators Mean?
When the USB device server option is correctly installed and recognized by the main machine, the LED indicators light
up under the following conditions.
Notes for Energy Save Mode Setting
If the USB device server option is installed and the machine enters into the energy save mode, you cannot print because
there will be a communication error. Follow the instructions below to prevent the machine from entering the energy save
mode.
1. Enter SP mode, and then set SP5-191-001 (Power Setting: Power Str) to "0 (Off)".
To Next Page
