2.Installation
45
14. Insert the Ethernet cable [A] into the Ethernet port on this option.
15. Insert the other end of the Ethernet cable to a PC for network settings.
16. Plug the power cord into the wall socket and turn ON the main power of the machine.
ï‚· Do not unplug the USB cable while the machine is trying to identify the USB Device Server Option. If
unplugged, connect the cable again.
ï‚· It may take between 30 seconds to 1 minute to finish identification (the LEDs on the Ethernet port of the
option light up when identification is completed).
17. To ensure that the machine recognizes the USB Device Server Option correctly, perform one of the following:
 Access the option’s IP address from a web browser.
 Ping the option’s IP address from a command prompt on a Windows PC in the same network as the main
machine.
If the IP address cannot be found (DHCP server), use the MAC address. This is the number printed on the seal
attached to the printed circuit board for the USB Device Server Option.
1. Use "RX" + the option’s MAC address and access a web browser.
Example: http://RX0080926A3264
