Ricoh M0A0 - Page 630

1.Installation
4
1. Remove the inquiry card from the handset cradle.
2. Remove the protective tape from the handset bracket, and fix the handset cradle [A] to the handset bracket [B].
3. Place the inquiry card back on the handset cradle.
4. Attach the bracket at the left side of the machine, as shown below.
