4.Service Tables
63
Communication Switch 01 (SP No. 1-104-002)
No
Function
Comments
0
ECM
0: Off 1: On
If this bit is set to 0, ECM is switched off for all communications.
In addition, V.8 protocol and JBIG compression are switched off automatically.
1
Not used
Do not change the setting.
2-
3
Wrong connection
prevention method
(0,1): The machine will disconnect the line without sending a fax message, if
the last 8 digits of the received CSI do not match the last 8 digits of the dialed
telephone number. This does not work when manually dialed.
(1,0): The same as above, except that only the last 4 digits are compared.
(1,1): The machine will disconnect the line without sending a fax message, if
the other end does not identify itself with an RTI or CSI.
(0,0): Nothing is checked; transmission will always go ahead.
 This function does not work when dialing is done from the external
telephone.
Bit 3
Bit 2
Setting
0
0
None
0
1
8 digit CSI
1
0
4 digit CSI
1
1
CSI/RTI
4-
5
Not used
Do not change the setting.
6-
7
Maximum printable page
length available
The setting determined by these bits is informed to the transmitting terminal in
the pre-message protocol exchange (in the DIS/NSF frames).
Bit 7
Bit
6
Setting
0
0
No limit
0
1
B4 (364 mm)
1
0
A4 (297 mm)
1
1
Not used
Communication Switch 02 (SP No. 1-104-003)
No
Function
Comments
0
G3 Burst error threshold
0: Low 1: High
If there are more consecutive error lines in the received page than the
threshold, the machine will send a negative response. The Low and
High threshold values depend on the sub-scan resolution, and are as
follows.
100 dpi
6(L) 12(H)
200 dpi
12(L) 24(H)
300 dpi
18(L) 36(H)
400 dpi
24(L) 48(H)
1
Acceptable total error line ratio
0: 5% 1: 10%
If the error line ratio for a page exceeds the acceptable ratio, RTN will
be sent to the other end.
