Configuration with the web interface
6-30 Chapter 6: Configuration 98-137654-A
The following parameters are recorded in the statistics report:
Parameter recorded Description
Hostname Host name, entered in the web interface
on the page SETTINGS > Network.
ACU SN ACU serial number
ADU SN ADU serial number
SW ver. Software version
System type SAILOR 100 Satellite TV
Table 6-8: Statistics report, header record
Parameter recorded Description
UTC. (s)
UTC (YYYY-MM-DD hh:mm)
UTC in seconds and date format for the data set.
RSSI.Av
RSSI.Max
RSSI.Min
Received signal strength (average, maximum and
minimum value) for the sampling interval.
POS.Lat (degree)
POS.Long (degree)
POS.Valid
Latitude value of position.
Longitude value of position.
Fix = valid position, No Fix = invalid position.
Heading.Samp (degree)
Heading.Max (degree)
Heading.Min (degree)
Heading.Range (+/-degree)
Ship’s heading (sample, maximum and minimum
value, range) for the sampling interval. See Figure 6-
23: Statistics — how to read data for a range.
Antenna.Azi (degree) Antenna.Azi
Max (degree) Antenna.Azi Min
(degree) Antenna.Azi Range (+/-
degree)
Current antenna azimuth (sample, maximum and
minimum value, range) for the sampling interval. See
Figure 6-23: Statistics — how to read data for a range.
Antenna.Ele (+/-degree)
Antenna.Ele Max (+/-degree)
Antenna.Ele Min (+/-degree)
Current antenna elevation (sample, maximum and
minimum value) for the sampling interval.
Tracking.rf freq (GHz)
Tracking.type
Tracking RF frequency for this record.
Narrow filter, DVB-S2 decoder.
Sat.long (degree) Longitude position of the satellite.
Pos Ok (%) Valid position, in percent of the sampling interval.
Blocking (%) Ship in blocking zone, in percent of the sampling
interval.
Table 6-9: Parameters recorded in a statistics report
