SAILOR 100 Satellite TV system components
A-4 Appendix A: Technical specifications 98-137654-A
A.1.3 ACU
A.1.4 Control Panel and SAILOR Transmodulator
For technical specifications see the documentation provided with the Control Panel.
For technical specifications see the documentation provided with the SAILOR Transmodulator.
Item Specification
Dimensions, rack mount
H x W x D
1.5 U, 19 inch
6.6 x 48 x 40 cm (2.6 x 19 x 15.75 inch)
Weight 6.2 kg (13.7 lbs)
Ambient temperature Operational: -15 or -25°C to +55°C
Storage: -40°C to +85°C
Humidity IEC 945 protected, 95% (non-condensing)
IP class IP31
Compass safe distance 1 m to IEC 945
Interfaces 1 x N-Connector for antenna RF Cable (50 Ohm) w.
automatic cable loss compensation
4 x F-Connectors (75 Ohm) for TV output
4 x Ethernet
2 x DB9 (reserved for future use)
1 x NMEA 2000 (CAN bus) and NMEA 0183 (RS-422) for
Gyro/GPS compass input
1 x DC power input
1 x Grounding bolt
Input power See System power supply range and Total system power
consumption on page A-1.
Man Machine Interface (MMI) OLED (red) display, 5 push buttons,
3 discrete indicator LEDs and ON/OFF switch
Table A-3: Technical specifications for the ACU
