Sailor 100 - Figure 8-100: Rotary Joint (Removed)

Removal and replacement of ADU modules
98-137654-A Chapter 8: Service & maintenance 8-77
8888
Service & maintenance
13. Remove the rotary joint.
8.5.11.2 Insert a new Rotary Joint.
To insert a new Rotary Joint follow the instructions above in reverse
order.
Figure 8-100: Rotary joint (removed)
