Sailor 100 - Appendix A Technical Specifications; SAILOR 100 Satellite TV System Components

98-137654-A A-1
Appendix A
AAAA
Technical specifications
Technical specifications A
A.1 SAILOR 100 Satellite TV system
components
A.1.1 General specifications
Item Specification
Frequency band
Rx
Ku-band
10.70 to 12.75 GHz
Reflector size 103 cm (40 inch)
Certification (approval) Compliant with CE (Maritime), CEI/IEC 60950-1,
CEI/IEC 60945, CEI/IEC 60950-22
ADU cable type (ACU to
ADU)
Single 50 Ohm coax cable for Rx, ACU-ADU modem and
power
ADU cable connector at the
ADU
Female N-Connector (50 Ohm)
ADU cable connector at the
ACU
Female N-Connector (50 Ohm)
System power supply range 20—32 VDC
(Start up voltage: 22 VDC guaranteed)
Total system power
consumption
260 W peak without SAILOR Transmodulator
367 W peak with SAILOR Transmodulator
Table A-1: General specifications
