Calibration of the SAILOR 100 Satellite TV
6-4 Chapter 6: Configuration 98-137654-A
6.2 Calibration of the SAILOR 100
Satellite TV
You must align the ADU with the vessel’s gyro compass. To do this,
you make an azimuth calibration, i.e. you determine the offset of the
ADU zero direction to the bow-to-stern line of the ship. This
procedure is fully automatic.
For a detailed introduction to the web interface see Overview and
navigation on page 6-8.
6.2.1 Heading and calibration of azimuth
Access the page for heading and calibration through SERVICE >
Calibration.
Important
You must logon as an administrator to do a
calibration. See Administration on page 6-33.
Figure 6-3: Web interface: SERVICE, Calibration
