Installation of the ADU
98-137654-A Chapter 3: Installation 3-17
3333
Installation
3.3 Installation of the ADU
The ADU is shipped fully assembled. You have to install it on the
mast and attach the ADU cable.
Before installing the ADU read the following guidelines.
WARNING! Use a strong webbed sling with a belt to
lift the ADU without damaging the radome. Make sure
that the sling can carry the ADU’s weight (126 kg,
278 lbs).
WARNING! The ADU may be subject to swaying
motions in windy conditions. Always use tag lines to
stabilise the ADU during hoisting.
Figure 3-13: Use of strong sling with a belt and tag lines for safe hoisting
Webbed sling with belt
Tag lines
SAILOR100TM.book Page 17 Tuesday, January 29, 2013 2:44 PM
