Removal and replacement of ADU modules
8-50 Chapter 8: Service & maintenance 98-137654-A
8.5.7 Replacing the Drive Belts
The ADU has 3 drive belts:
• X Elevation drive belt
• Elevation drive belt
• Azimuth drive belt
For step-by-step instructions see:
Removing the X Elevation Drive Belt on page 8-50
Inserting a new X Elevation Drive Belt on page 8-52
Removing the Elevation Drive Belt on page 8-53
Inserting a new Elevation Drive Belt on page 8-55
Removing the Azimuth Drive Belt on page 8-55
Inserting a new Azimuth Drive Belt on page 8-58
Removing the Polarisation Drive Belt on page 8-58
Inserting a new Polarisation Drive Belt on page 8-60
8.5.7.1 Removing the X Elevation Drive Belt
To remove the X Elevation Drive Belt, do as follows:
1. Open the service hatch by releasing the two latches with Torx
screws.
2. Switch off the power to the antenna on the service switch.
Tools needed:
• 4 x 150 mm Allen key
(located inside the
service door of the ADU)
• Acoustic frequency meter
