SAILOR 100 Satellite TV system components
A-2 Appendix A: Technical specifications 98-137654-A
A.1.2 ADU
Item Specification
Dimensions (overall) Diameter x Height: Ø 130 cm (51.3 inch) x H 150 cm (58.9 inch)
Weight 126 kg (278 lbs)
Antenna type, pedestal 3-axis (plus skew) stabilised tracking
ADU with integrated
GPS
Antenna type, reflector
system
Reflector/sub-reflector, ring focus
Receive Gain 40.1 dBi typ. @ 11.70 GHz (excluding radome)
System G/T 20.0 dB/K typ. @ 11.70 GHz, at 20° elevation and clear sky
(including radome)
LNB Whole band worldwide, single cable
Tracking Receiver Internal whole-band DVB-S2 type supporting QPSK/8PSK
and RSSI
Polarisation Linear and circular polarisation (automatic switch)
Elevation Range -25° to +125°
Azimuth Range Unlimited (Rotary Joint)
Ship motion, angular Roll ±30°, Pitch ±15°, Yaw ±10°
Ship, turning rate and
acceleration
15°/s and 15°/s
2
ADU motion, linear Linear accelerations ±2.5 g max any direction
Satellite acquisition Automatic - w. Gyro/GPS compass input
Vibration, operational Sine: IEC 945 (8.7.2), DNV A, MIL-STD-167-1 (5.1.3.3.5).
Random: Maritime
Table A-2: Technical specifications for the Above Deck Unit
