Configuration
6.5.3.1 Top-level menu
6.5.3.2 Menu descriptions
Top-level
menu
Description
MAIN View with current status of the SAILOR 100 Satellite TV. This
view is displayed after a time out of 10 minutes. Press any key
(except left arrow) to enter the menu at MAIN.
New events are shown in this display. If an event is displayed,
press OK to jump directly to the menu EVENTS for viewing the
currently active events.
ANTENNA Shows the current ADU parameters, position, software version
and serial numbers of the ADU and ACU.
NETWORK Shows the IP addresses and netmasks of the LAN connectors of
the ACU.
SATELLITE Current satellite information. This information is selected using
the web interface or the Control Panel.
EVENTS View system events. Active events are shown as: X ACTIVE
EVENTS in the MAIN display. Press OK to update the list.
Table 6-11: Top-level menus of the ACU
ANTENNA
menu
Description
POINTING ANTENNA STATE: Current state of the antenna, e.g.
TRACKING
ELEVATION: Current elevation angle of the antenna
AZIMUTH: Current azimuth of the antenna, with reference
to North
POLARISATION RX POLARISATION: Setting of polariser.
GPS LATITUDE: current latitude, read from GPS module.
LONGITUDE: current longitude, read from GPS module.
FIX TYPE: 3D or NONE
HEADING Ship’s heading in degrees with reference to North,
provided by the ship’s gyro.
VERSIONS Current software version.
Table 6-12: ANTENNA menu of the ACU
