Keypad and menus of the ACU
6-48 Chapter 6: Configuration 98-137654-A
SERIAL
NUMBERS
ACU: ACU serial number;
ADU: Serial number of the antenna
ANTENNA
menu
Description
Table 6-12: ANTENNA menu of the ACU (Continued)
NETWORK menu Description
PORT 1/2 IP Current IP address for LAN 1 and LAN 2.
MASK 1/2 Current netmask for LAN 1 and LAN 2.
PORT 3 IP (LAN 3) Current IP address of the SAILOR 100 Satellite
TV web interface (default: 192.168.0.1).
MASK 3 (LAN 3) Current netmask of the SAILOR 100 Satellite TV
web interface (default: 255.255.255.0).
PORT 4 IP Current IP address for LAN 4.
MASK 4 Current netmask for LAN 4.
DEFAULT GATEWAY Current default gateway.
Table 6-13: NETWORK menu of the ACU
SATELLITE menu Description
POSITION Position of the current satellite.
RX POLARISATION Linear polarisation: HORIZONTAL, VERTICAL.
Circular polarisation: LEFT HAND, RIGHT HAND.
RX FREQUENCY Ku band receiving frequency of the active satellite.
LNB LO HIGH Current LNB Local Oscillator frequency, high band
(GHz), selected in the satellite profile.
LNB LO LOW Current LNB Local Oscillator frequency, low band
(GHz), selected in the satellite profile.
Table 6-14: SATELLITE menu of the ACU
