Unpacking
3-2 Chapter 3: Installation 98-137654-A
3.1.2 Control Panel
Unpack your Control Panel and check that the following items are
present:
• DC Power Cable
• Knob
• U-Bracket Mount
• Flush Mount Gasket
•Screw Kit
• Cable Relief Plate
• Installation manual
3.1.3 Initial inspection
Inspect the shipping cartons and wooden box immediately upon
receipt for evidence of damage during transport. If the shipping
material is severely damaged or water stained, request that the
carrier's agent be present when opening the cartons and wooden
box. Save all box packing material for future use.
After unpacking the system, i.e. removing the top and sides of the
wooden box and opening the cartons, inspect it thoroughly for
hidden damage and loose components or fittings. If the contents are
incomplete, if there is mechanical damage or defect, or if the system
does not work properly, notify your dealer.
3.1.4 Tools needed
• Unbraco key (5 mm), included, mounted on a tool holder inside
the radome.
Other tools that may be needed during the installation:
• Torx TX20 to open the locks of the service hatch
• Wrench to fasten the mounting bolts for the ADU
• Wrench to fasten the N connector at the ADU
WARNING! To avoid electric shock, do not apply
power to the system if there is any sign of shipping
damage to any part of the front or rear panel or the
outer cover. Read the safety summary at the front of
this manual before installing or operating the system.
