Interfaces of the SAILOR 100 Satellite TV ACU
4-4 Chapter 4: Interfaces 98-137654-A
4.1.6 TV output connectors (x4)
Connect V Low, H Low, V High and H High to the matching
connectors of the Multiswitch.
Connect V Low, H Low, V High, and H High to the corresponding
connectors of the Multiswitch or SAILOR Transmodulator.
In circular mode RHCP is delivered on the vertical ports (VL and VH)
and LHCP is delivered on the horizontal ports (HL and HH).
4.1.7 DC output connector
Connector for internal use (cable already connected).
Outline (on the ACU) Conductor Pin function
Inner Rx (950 — 2150 MHz)
Outer GND (Shield)
Table 4-3: F connector, Rx, outline and pin assignment
Note
Systems with circular polarisation typically use the high band only (connectors
V High and H High).
