98-137654-A 5-1
Chapter 5
5555
Connecting power
Connecting power 5
This chapter is organised in the following sections:
• Power source
• Power cable selection
• Connecting power
• Power up
5.1 Power source
There are different options for the power supply:
• The 24 VDC ship supply provides power for the ACU.
• An AC line provides power through an AC/DC power supply. The
TT-6080A Power Supply is recommended.
In order to protect against short circuit in the power
cable/connector, the ship’s DC outlet must be protected by a 30 A
fuse or circuit breaker.
Note
Be aware of high start-up peak current: 35 A at 24 VDC,
5 ms.
SAILOR100TM.book Page 1 Tuesday, January 29, 2013 2:44 PM
