List of ADU events
C-2 Appendix C: System messages 98-137654-A
C.2 List of ADU events
Error
code (ID)
Unit Severity Description Explanation
0A001-0 Antenna ERROR Production data Production data is invalid.
0A002-0 Antenna ERROR XIM internal Antenna configuration data stored in the PCM
module is invalid.
0A003-0 Antenna ERROR XIM external Antenna configuration data stored in the VIM/TIM
module is invalid.
0A004-0 Antenna ERROR XIM I/X match Antenna configuration data stored in the PCM
module does not match the configuration data
stored in the VIM/TIM module.
0A005-0 Antenna ERROR Antenna type The configured antenna type is not supported or
unknown.
0A006-0 Antenna ERROR PCM FPGA load The PCM FPGA cannot be initialised and loaded
correctly.
0A007-0 Antenna ERROR XIM FPGA load The VIM/TIM FPGA cannot be initialised and
loaded correctly.
0A008-0 Antenna ERROR XIM production Production/calibration data stored in the VIM/TIM
module is invalid.
0A00A-0 Antenna ERROR GPS initialisation The GNSS device cannot be initialised. Check
cable and GNSS device.
0A014-0 Antenna ERROR AMB device
discovery
Missing one or more of the following devices: ISM,
DDM and PMM. Check cables.
0A015-0 Antenna ERROR Azi DDM ABS device Cannot initialise the azimuth DDM. Info:
0x00000000: Device not found (possible
cabling problem)
0x0000bbaa: Device internal error (replace
device)
aa=status, bb=state.
0A016-0 Antenna ERROR Xel DDM ABS device Cannot initialise the cross-elevation DDM. Info:
See 0A015-0.
0A017-0 Antenna ERROR Ele DDM ABS device Cannot initialise the elevation DDM. Info: See
0A015-0.
Table C-1: ADU event messages
