Removal and replacement of ADU modules
98-137654-A Chapter 8: Service & maintenance 8-11
8888
Service & maintenance
8.5 Removal and replacement of ADU
modules
All replacement of modules must be carried out by a Thrane &
Thrane A/S service partner. The figure below shows the modules
and their position. Some modules are equipped with LEDs for status
information and troubleshooting.
For instructions on how to open and remove the service hatch see
Opening and removing the service hatch on page 3-21.
1. GPS module.
Figure 8-6: ADU modules and motor stop switch
