Chapter 7
7777
Installation check
Installation check 7
Now that you have installed the system, you can test it to verify it is
ready for customer delivery. Follow the check lists below to test the
system for proper operation.
• Installation check list: Antenna
• Installation check list: ACU, connectors and wiring
• Installation check list: Control Panel
• Installation check list: Functional test in harbor
7.1 Installation check list: Antenna
Step Task Further information Done
1.
Check that the antenna is free
of obstructions.
See Obstructions (ADU
shadowing) on page 3-4.
2.
Make sure there is sufficient
space for access through the
service hatch.
See Installing the ADU on
page 3-18.
3.
Make sure to maintain the
vertical orientation of the ADU
center line.
4.
Check that the ADU is installed
where vibrations are limited to
a minimum.
5.
Check that you programmed
the blocking zones correctly.
See Blocking zones —
azimuth and elevation on
page 3-5
and
Setting up Blocking zones
on page 6-23
6.
Check that the mounting
height of the antenna is in
accordance with the ship’s
min. roll period.
See Ship motion and offset
from the ship’s motion
centre on page 3-6.
Table 7-1: Installation check list: Antenna
