List of ADU events
C-4 Appendix C: System messages 98-137654-A
0A034-0 Antenna WARNING ACU communication The communication link between ACU and
antenna is down.
0A035-0 Antenna WARNING ISM data valid Sensor measurements from the ISM are invalid.
This indicates a malfunctioning ISM.
0A036-0 Antenna WARNING ISM data range Sensor measurements from the ISM are out of
range.
0A037-0 Antenna WARNING GNSS
communication
Lost connection to the GNSS device.
0A038-0 Antenna WARNING GNSS data range Received information from the GNSS device which
is out of range.
0A039-0 Antenna WARNING GNSS device
warning
Local GNSS device warning.
0A03A-0 Antenna WARNING GNSS device error Local GNSS device error.
0A03B-0 Antenna ERROR Azi DDM shutdown The azimuth motor control has detected one of the
following situations: Extreme temperature,
voltage, current or velocity. The motor was then
shut down. This is usually a temporary situation
and is probably fixed by a restart of the system.
0A03C-0 Antenna ERROR Xel DDM shutdown As Azi DDM shutdown but detected by the cross-
elevation motor control.
0A03D-0 Antenna ERROR Ele DDM shutdown As Azi DDM shutdown but detected by the
elevation motor control.
0A03E-0 Antenna ERROR PMM shutdown As Azi DDM shutdown but detected by the
polarisation motor control.
0A03F-0 Antenna WARNING AMB timing This indicates a busy situation. It may occur
during installation procedures. No user
interaction is required.
0A043-0 Antenna WARNING LNB voltage low The voltage for the LNB is too low probably caused
by a malfunctioning VIM/TIM or LNB.
0A044-0 Antenna WARNING LNB voltage high The voltage for the LNB is too high probably
caused by a malfunctioning VIM/TIM.
0A047-0 Antenna ERROR VIM PLL lock The PLL of the VIM/TIM is out of lock. Check the 10
MHz reference signal.
0A048-0 Antenna WARNING VIM tuner lock The PLL of the second receiver (DVB) is out of lock.
Check the 10 MHz reference signal.
Error
code (ID)
Unit Severity Description Explanation
Table C-1: ADU event messages (Continued)
