List of ADU events
C-6 Appendix C: System messages 98-137654-A
0A057-0 Antenna WARNING Ele DDM warning The elevation motor controller has temporarily
observed an unusual situation with regards to
temperature, voltage, current or velocity. No user
interaction required.
0A058-0 Antenna WARNING PMM warning The polarisation motor controller has temporarily
observed an unusual situation with regards to
temperature, voltage, current or velocity. No user
interaction required.
0A059-0 Antenna WARNING Azi cal. limits Azimuth axis calibration result check limits
exceeded. Pointing performance may be
degraded. Info:
0x00000040: End stop detected before expected
limit
0x00000100: Zero width is low 0x00000200:
Zero width is high 0x00000400: Zero slack is
high 0x00001000: Friction average is high
0x00002000: Friction peak is high
0x00004000: Friction asymmetry is high Zero
width low/high: Zero reference module placement
may be incorrect. Zero slack high: Mechanical
slack may be too high. Friction average/peak
high: Mechanical friction is higher than expected.
Friction asymmetry high: Mechanical imbalance
may be too high.
0A05A-0 Antenna WARNING Xel cal. limits Cross-elevation axis calibration result check limits
exceeded. Pointing performance may be
degraded. Info: See 0A059-0.
0A05B-0 Antenna WARNING Ele cal. limits Elevation axis calibration result check limits
exceeded. Pointing performance may be
degraded. Info: See 0A059-0.
0A05D-0 Antenna WARNING ISM warning The ISM has temporarily observed an unusual
situation with regards to temperature or voltage.
No user interaction required. If repeated after
cooldown and reboot, the ISM or cables around it
may be defective.
0A05F-0 Antenna WARNING Heading range Heading data range error. External heading unit
supplies unreliable data.
0A060-0 Antenna ERROR LNB error The LNB is not working as intended.
0A061-0 Antenna ERROR LNB PLL lock The LNB PLL is out of lock.
Error
code (ID)
Unit Severity Description Explanation
Table C-1: ADU event messages (Continued)
