C-8 Appendix C: System messages 98-137654-A
08072-0 ADM ERROR User defined satellite
data
There is an error in the satellite database. The
data describing the satellite selected in the active
satellite profile is corrupt. Edit the respective user
defined satellite entry and correct its data.
08075-0 ADM WARNING Rx cable calibration The Calibration of the ACU-ADU cable failed.
Cable could be defective, too long, of too poor
quality, not properly connected, or the TIM or
AMB hardware could be defective.
08077-0 ADM ERROR Satellite profile
frequency setup
There is an error in the frequency parameters of
the active satellite profile. Please edit the active
satellite profile and change the erroneous
frequencies. (!V,!G)
08078-0 ADM WARNING SAILOR Transmodulator
connection
Connection to one or more SAILOR
Transmodulator modules is lost.
08100-0 ADM ERROR PSM low voltage (22 V) The ADM measures a different ADU voltage than
expected. If the problem is not solved by a
restart, and the PSM is not reporting any errors,
the ADM is probably defective.
08101-0 ADM ERROR PSM high voltage (48 V) The ADM measures a different ADU voltage than
expected. Check for short circuit of the antenna
coax connector. If the problem is not solved by a
restart, and the PSM is not reporting any errors,
the ADM is probably defective.
08102-0 ADM ERROR PSM 5 V power Internal voltage supply error of the ADM.
08103-0 ADM ERROR ADM hotswap The ACU is not able to supply the correct voltage
to the antenna. Check for short circuits in coax
cable and the antenna
08104-0 ADM ERROR ADU communication The ACU cannot communicate with the antenna.
Check cable and antenna.
08107-0 ADM ERROR ADM FPGA load The ADM FPGA cannot be initialised and loaded.
08109-0 ADM ERROR ADU XIM data There is a mismatch with the antenna
configuration data. Either the PCM or the VIM in
the antenna are malfunctioning or one of them
has been replaced. In the latter case, select
which is the original device in the web interface
and restart the system.
0810A-0 ADM ERROR ADM production data Production data has been corrupted.
Error
code (ID)
ACU
PCB
Severity Description Explanation
Table C-2: ACU event messages (Continued)
