Sailor 100 - Information Fields on the Dashboard

Configuration with the web interface
98-137654-A Chapter 6: Configuration 6-13
6666
Configuration
Tracking
polarisation
Linear polarisation: Horizontal, Vertical.
Circular polarisation: Left-hand, Right-hand.
Tracking RF
frequency
Current RF tracking frequency.
LNB LO Frequency
high band
Current LNB Local Oscillator frequency, high band (GHz),
selected in the satellite profile.
LNB LO Frequency
low band
Current LNB Local Oscillator frequency, low band (GHz),
selected in the satellite profile.
ACU part name, ADU
part name, ACU
serial number, ADU
serial number,
Software version
Part names, serial numbers for ACU and ADU, software version
of the SAILOR 100 Satellite TV.
SAILOR 100 Satellite
TV parameter
Description
Table 6-5: Web interface, DASHBOARD, SAILOR 100 Satellite TV parameters (Continued)
POINTING
parameter
Description
Azimuth relative Current value for azimuth, relative to the vessel heading.
Elevation relative Current value for elevation, relative to the vessel.
Polarisation skew Current value for polarisation skew.
Table 6-6: Web interface, DASHBOARD, POINTING parameter
