Vista Digital Mixing System
Date printed: 05.08.03 SW V3.3 Parameters 3-29
from 0 to –∞ dB while the left channel remains at full input level, and vice
versa.
The INP DIR function is used to control the direction of a stereo input
signal. Turning the rotary encoder shifts the input direction in 1° steps
from –30° (left) to +30° (right).
ST DIR [72] Left/right (odd/even) panning control for a stereo output signal in 1° steps
from –30° (left) to +30° (right).
* DIR WIDTH On/Off [73] Switches the DIR WIDTH function on/off.
* DIR WIDTH [74] The DIR WIDTH parameter is used to control the width of the stereo sig-
nal. It is only functional if there is a difference between the left and right
input channels, or if IBAL or IDIR has been used to create an offset be-
tween the channels. The ST DIR control [72] directs the position of the
stereo signal, while the DIR WIDTH control determines the width or ste-
reo spread either side of that position. DIR WIDTH operates over a range
from 0% (mono) to 200% (“super stereo”).
* Optional parameters, only if the width function is configured.
