Vista Digital Mixing System
30 Software V4.0 SW V4.0 Date printed: 17.06.08
B.3 Global View
B.3.1 Vintage Compressor Parameters
Press GLOBAL VIEW: COMP-LIM.
This global view enables the user to control the most important parameters
of the vintage dynamics section’s compressor part. The complete parameter
set is available on the channel-related vintage dynamics view, refer to
chapter B.4.1. There you will also find the parameter details.
CMP THRS [1] The compressor threshold level can be adjusted in 1 dB steps from 0 dB
FS
to –96 dB
FS
.
CMP RTIO [2] The compressor ratio
can be adjusted from 1:1 (no compression) to 40:1
(heavy compression or limiting).
CMP peak/RMS [3] Level detection mode: peak or RMS
CMP ATCK [4] The compressor attack time can be adjusted in 64 steps within a range of
0.2 ms to 250 ms.
MKUP GAIN [5] Manual gain compensation from 0 dB to +24 dB
MKUP GAIN auto on/off [6] Auto Make-up Gain function on/off.
[1]
[2]
[3]
[4]
[5]
[6]
