Vista Digital Mixing System
Date printed: 05.08.03 SW V3.3 Parameters 3-21
Frequency [32] Cutoff frequency adjustment for the high- and low-cut filter: 20 Hz
through 20 kHz, in 120 steps.
Notch Filter Parameters: Please note that these two fields only appear if the notch filter is config-
ured (i.e., “EQ with Notch” is selected for this channel in the console con-
figuration).
NOTCH On/Off [33] On/off function for the notch filter.
Frequency [34] Center frequency for the notch filter: 20 Hz through 20 kHz, in 120 steps.
Notch Q [35] The notch filter’s Q is selectable from two fixed values; W (wide, Q=2),
and N (narrow, Q=10).
Please note that there are EQ, HI CUT and LO CUT hardware keys below the
channel meters for activating or deactivating EQ and filter sections, in ad-
dition to the individual On/Off keys for each EQ band.
