Engineer programming via the browser
Connecting to the panel via USB
Installation & Configuration Manual
8. Select if this connection is available to all users or just yourself.
9. On the last dialog of the wizard, click Finish.
10. The PC prompts for username and password for the USB connection. Enter the
following details:
- Username: SPC
- Password: password (default)
11. Click Connect.
The PC initiates a data link with the controller. When the link has been
established, a connection icon appears on the task bar at the bottom of the
PC screen.
12. Right-click the link and select Status.
A server IP address is displayed in the details window.
13. Enter this address into the address bar of an internet browser using the hyper
text transfer protocol secure (e.g. https://192.168.5.1).
14. Login into the SPC browser application using your user PIN.
Your default PIN should be changed immediately and noted. Forgotten PINs are
remedied only by a factory default of the system, resulting in a reset of the system
configuration. The configuration can be restored if a backup is available.
Windows 7
Perform all actions described in USB Connection on Windows 7 for SPCPro
You must have Local Administrator rights to perform the actions in this task.
1. Open the Windows 7 Control Panel.
2. Select Phone and Modem.
The Phone and Modem window is displayed,
3. Select the Modems tab and click Add.
The Add Hardware Wizard – Install New Modem window is displayed.
4. Click Next twice.
The Add New Hardware wizard displays a list of modems.
5. Select Communications cable between two computers.
6. Click Next.
7. Select the COM port assigned in USB Connection on Windows 7 for SPCPro.
8. Click Next, then Finish.
9. Return to the Modems tab of the Phone and Modem window.
10. Select the new modem and click Properties.
The Communications cable between two computers Properties window is
displayed.
11. In the General tab, click Change Settings to allow editing of the properties.
12. Select the Modem tab.
13. Change the value in the Maximum Port Speed to 115200 and click OK.
