Engineer programming via the browser
Configuring Communications
Installation & Configuration Manual
Quick start configuration screen for an EN50136 Single Path ATS, Dual Path
ATS and Dual Path Dual Server ATS
Default Event Profile
Default Command Profile (this does not support audio video verification)
Default FlexC Command User Name (FlexC) and Command Password (FlexC)
for controlling the panel from the RCT (e.g. SPC Com XT)
Auto Encryption with no password
1. To quickly configure a FlexC connection between a panel and an RCT (e.g.
SPC Com XT), go to Communications - FlexC - FlexC ATS.
2. Under Add EN50136-1 ATS, choose one of the following to display the ATP
Configuration screen:
Add Single Path ATS - primary ATP only
Add Dual Path ATS - primary and backup ATPs
Add Dual Path Dual Server ATS - primary and backup ATPs, primary and
backup servers
1. Complete the fields on the ATP Configuration - EN50136 ATS screen shown in
the table below. At a minimum, you must complete the field RCT URL or IP
Address to save. If you do not enter an SPT Account Code, you can
commission the panel using the ATS Registration ID which is automatically
generated when you save. The RCT operator must enter this ATS Registration
ID, for example, in SPC Com XT.
2. Click Save. The ATS Configuration screen displays showing the ATS
Registration ID and the configured primary ATP or primary and backup ATPs in
the Event Sequence Table.
3. On the ATS Configuration screen, click Save to accept the default settings, for
example, the Default Event Profile, the Default Command Profile (including the
FlexC Command User Name and FlexC Command Password), and Auto
Encryption with no password. To change the settings, see Configuring an
EN50136-1 ATS or Custom ATS [➙ 276].
4. Click Back. The ATS displays in the Configured ATS table.
