Technical Data
SPC5000
34
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Mains fuse
 SPC5320/5330: 250 mA T (replaceable part on mains
terminal block)
 SPC5350 : 800mA T (replaceable part on mains
terminal block)
Power consumption
 SPC5320/5330: Max. 200 mA at 230 VAC
 SPC5350: Max. 500mA at 230 V AC
Operating current
 SPC5320/5330: Controller: Max. 200 mA at 12 VDC
 SPC5350: Max. 210 mA at 12 VDC
Quiescent current
SPC53xx Controller: Max. 170 mA at 12 VDC (195 mA
with PSTN, 300 mA with GSM, 325 mA with PSTN &
GSM)
Output voltage
13-14 VDC in normal conditions (mains powered and fully
charged battery), min. 10.5 VDC when powered by
secondary device (before system shut down to battery
deep discharge protection)
Low voltage trigger
11 VDC
Overvoltage protection
 SPC5320/5330: 15.7 VDC
 SPC5350: 15 VDC nominal
Peak to Peak ripple
Max. 5 % of output voltage
Auxiliary power (nominal)
 SPC5320/5330: Max. 750 mA at 12 VDC
 SPC5350: Max. 2200 mA at 12 VDC (8 separately
fused outputs, 300 mA per output)
Battery type
 SPC5320: YUASA NP7-12FR (7 Ah),
 SPC5330: YUASA NP17-12FR (17 Ah)
 SPC5350: YUASA NP24-12 (12 V 24 Ah), Alarmcom
AB1227-O (12 V 27 Ah)
 SPC5350: FIAMM FGV22703 (12V 27Ah)
Battery not supplied
Battery charger
 SPC5320: Max. 72h,
 SPC5330/5350: Max. 24h to 80% of battery capacity
Battery protection
 SPC5320/5330: Current limited to 1 A (fuse
protected), deep discharge protection at 10.5 VDC +/-
3 %
 SPC5350: Current limited to 2 A (protected by PTC
resettable fuse), deep discharge protection at 10.5
VDC
Software update
Local and remote upgrade for controller, peripherals and
GSM/PTSN modems.
Calibration
No calibration checks required (calibrated at
manufacturing)
Serviceable parts
 SPC5320/5330: No serviceable parts
 SPC5350: 8 glass fuses (400mA AT) for 12 VDC
outputs
Operating temperature
-10 ~ +50 °C
Relative humidity
Max. 90 % (non condensing)
Colour
RAL 9003 (signal white)
Weight
 SPC5320: 4.500 kg
 SPC5330: 6.400 kg
 SPC5350: 18.600 kg
