Vanderbilt SPC53 Series User Manual

Technical Data
4
SPC6000
37
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Output voltage
 SPC6330: 13-14 V DC in normal conditions (mains
powered and fully charged battery), min. 10.5 V DC
when powered by secondary device (before system
shut down to battery deep discharge protection)
 SPC6350: 13-14 V DC in normal conditions (mains
powered and fully charged battery), min. 10.5 V DC
when powered by secondary device (before system
shut down to battery deep discharge protection)
Low voltage trigger
11 V DC
Overvoltage protection
 SPC6330: 15.7 V DC
 SPC6350: 15 V DC nominal
Peak to Peak ripple
Max. 5 % of output voltage
Auxiliary power (nominal)
 SPC6330: Max. 750 mA at 12 V DC
 SPC6350: Max. 2200 mA at 12V DC (8 separately
fused outputs, 300 mA per output)
Battery type
 SPC6330: YUASA NP17-12FR (17 Ah)
 SPC6350: YUASA NP24-12 (12 V 24 Ah), Alarmcom
AB1227-O (12 V 27 Ah)
 SPC6350: FIAMM FGV22703 (12V 27Ah)
Battery not supplied
Battery charger
SPC63xx: Max. 24h to 80% of battery capacity
Battery protection
 SPC6330: Current limited to 1 A (fuse protected), deep
discharge protection at 10.5 V DC +/- 3 %
 SPC6350: Current limited to 2 A (protected by PTC
resettable fuse), deep discharge protection at 10.5 V
DC, low voltage indicator at 11 V DC
Software update
Local and remote upgrade for controller, peripherals and
GSM/PTSN modems.
Calibration
No calibration checks required (calibrated at manufacturing)
Serviceable parts
 SPC6330: No serviceable parts
 SPC6350: 8 glass fuses (400mA AT) for 12 V DC
outputs
Operating temperature
-10 ~ +50 °C
Relative humidity
Max. 90 % (non condensing)
Colour
RAL 9003 (signal white)
Weight
 SPC6330: 6.400 kg
 SPC6350: 18.600 kg
Dimensions (W x H x D)
 SPC6330: 326 x 415 x 114 mm
 SPC6350: 498 x 664 x 157 mm
Housing
 SPC6330: Hinged metal housing (1.2 mm mild steel)
 SPC6350: Metal housing (1.5 mm mild steel)
Housing can contain up to
 SPC6330: 4 additional expanders (size 150 mm x 82
mm)
 SPC6350: 6 additional expanders (150 x 82 mm) or 1
additional controller + 4 expanders
IP / IK Rating
30 / 06
ATS
10
ATP
30
Event Profiles
20
Event Exceptions
100
