Vanderbilt SPC53 Series User Manual

6
Mounting system equipment
Mounting a G3 housing
46
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
1
Enclosure
3
Wall Fixing Plate
2
Wall
4
Tamper Switch
WARNING
If the wall fixing plate is not accurately aligned then the enclosure will not sit
properly on its fixings.
Wiring the Back Tamper Switch to the Control Panel
All control panels have spare inputs configured as tamper inputs that are designed
for wiring the tamper switch and do not require any programming.
This tamper switch will be referred to as ‘Aux Tamper 1’ by the system.

Vanderbilt SPC53 Series Specifications

General

Brand	Vanderbilt
Model	SPC53 Series
Category	Power Supply
Language	English
