Controller Hardware 42xx\43xx\53xx\63xx
Installation & Configuration Manual
This USB interface is used to access browser programming or a terminal
program.
This RS232 serial port may be used to interface to an external modem or
PC terminal program. Serial port 2 shares a communications channel
with the back-up modem. If a back-up modem is installed, ensure no
devices are connected to this serial port.
This RS232 serial port may be used to interface to an X10 protocol
device.
A primary (left slot) and back-up (right slot) module can be connected to
the controller. These modules can be GSM or PSTN modems offering
increased communication functionality. The back-up modem should not
be connected if serial port 2 interface is connected to an external modem
or other device.
This on-board front tamper (switch & switch) provides the cabinet tamper
protection.
Note: The front tamper is not used in the G5 housing.
J12: Fit jumper for 17 Ah battery use and remove for 7 Ah battery.
Please Note: This selector is only available on 2.3 revision controller
PCB.
(Not applicable for SPC5350 and SPC5360 panels)
12 v input from battery or PSU**.
* Default setup for SPC5350 and SPC5360 panels
** PSU only applies to SPC5350 and SPC6350 panels.
