Wiring the system
Installing plug-in modules
88
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
WARNING
Modems are not plug and play. You must log on to the panel as Full Engineer,
then power the controller board down before installing, removing or moving
modems from one position to the other. After completing the modem task,
reconnect the system to the power supply and log on to the controller as Full
Engineer again. Configure and save the configuration. Failure to follow this
process results in a CRC error.
Plug-in modules
1
Wireless receiver slot
2
Primary modem slot
3
Back-up modem slot
For installation please refer to the corresponding Installation Instruction.
